95.5mm | 3.1-3.7X | F3.7-F11 | φ67mm – 16K Large Format Line Scan Lens

Features

• Suitable for use with IMX411 seonsor (151MP, 3.75μm pixel size) and 150MP line scan cameras.
• Features high resolution, high brightness, and excellent image quality consistency.
• Specialized broadband multi-layer coating technology ensures good transmittance in the 400-1100nm wavelength range.
• Maximum image-square FOV φ67mm: Suitable for wide-FOV cameras to meet broader inspection requirements.
• Easy installation and setup: The V-mount allows for easy adjustment of rotation angles while maximizing structural stability.
• Vignetting is almost completely eliminated: Excellent image quality is achieved with almost complete vignetting reduction.
• Wide adjustable aperture range: Even at maximum aperture, it still provides image-square resolution up to 100 lp/mm.
• Supports magnification adjustment between 0.03-5.9X, exhibiting excellent distortion performance across the entire magnification range.

Meets the needs of high-speed, high-precision inspection applications, such as glass covers, display panels, semiconductors, and PCBs.
