Varifocal Lens Series
Varifocal Lens Series
If you don’t find the lens you need, you can contact customer service directly for more lens recommendations and information.
Model No. | Focal Length | Sensor Size | F No. | Focus Range | Filter Size | TV Distortion | Mount | Dimensions | Operation | ||
Iris | Focus | Zoom | |||||||||
5mm | 1/1.8” | F2.4～C | 200mm~Inf. | M35.5 ,P=0.5mm | -0.87% | C-Mount | Φ37.5×45.3mm | Manual | Manual | Manual | |
12mm | 1/1.8” | F2.4～C | 100mm～Inf. | M35.5 ,P=0.5mm | 0.1% | ||||||
10mm | 2/3” | F2.8～C | 100mm~Inf. | M35.5 ,P=0.5mm | -0.74% | C-Mount | Φ37×58.6mm | Manual | Manual | Manual | |
40mm | 2/3” | F2.8～C | 200mm～Inf. | M35.5 ,P=0.5mm | 0.28% | ||||||
10mm | 1/1.7” | F2.8～C | 100mm~Inf. | M35.5 ,P=0.5mm | -0.1% | C-Mount | Φ37.5×64.2mm | Manual | Manual | Manual | |
55mm | 1/1.7” | F2.8～C | 200m～Inf. | M35.5 ,P=0.5mm | 0.05% | ||||||
12-36mm | 1/1.8" | F2.8～F16 | 150m～Inf. | M35.5 ,P=0.5mm | 0.11% | C-Mount | Φ33.0×42.54mm | Manual | Manual | Manual | |
12-36mm | 2/3" | F2.8～C | 150m～Inf. | M40.5 ,P=0.5mm | -3.43% | C-Mount | - | Manual | Manual | Manual | |
10-50mm | 1/1.8″ | F2.8～C | 100mm~Inf. | M35.5 ,P=0.5mm | -5.32% | C-Mount | Φ37×63.56mm | Manual | Manual | Manual | |
20-70mm | 1/1.2" | F1.3-F1.5 | 3m~5m | - | -7.50% | CS-Mount | Φ60x108.75mm | P-Iris | Manual | Manual | |
20-70mm | 1/1.2" | F1.3-F1.5 | 3m~5m | - | -7.50% | CS-Mount | Φ60x109.1mm | P-Iris | Motorized | Motorized | |
