29mm | 0.5X | F9.0 | 14μ – 4K7μ Line Scan Telecentric Lens

Features

• Optimized for 4K line scan cameras, supports image planes up to 29mm, ensuring uniform images without black corners in the entire field of view
• Without distortion, ensuring consistency of dynamic repeatability measurement results
• High telecentricity design, minimum telecentricity of the full field of view is less than 0.1°
• Suppress stray light design to eliminate interference with imaging quality

4K7μ line scan telecentric lens, a special optical device designed for high-precision industrial inspection needs. Suitable for semiconductor packaging inspection, precision electronic measurement, high-speed line scan inspection and other scenarios

Resources

Download Datasheet(PDF)
