1.1″ | 2X | F7.1-F16 | 0.08mm@3.45μm – Object Telecentric Lens

Features

• Perfect image quality, supports 10MP digital cameras;
• High contrast, low distortion, ultra-clear;
• Full range of object-side telecentric fixed-magnification lenses, with multiple working distances/magnifications/CCDs to choose from;
• Widely used in high-precision visual positioning and other applications.

Suitable for semiconductor inspection, transparent material inspection, glass bottle defect recognition, high-speed measurement and other industry applications, online screening of lithium electrode coating defects.

Resources

Download Datasheet(PDF)
