1.1″ | 0.8X | F7 | 1.2mm – Bi-Telecentric Lens

Features

• High telecentricity design, minimum telecentricity of full field of view is less than 0.2°
• Maximum distortion <0.22%, ensuring consistency of dynamic repeatability measurement results
• Suppress stray light design, eliminate interference with imaging quality
• Large depth of field design

Suitable for semiconductor inspection, transparent material inspection, glass bottle defect recognition, high-speed measurement and other industry applications, online screening of lithium electrode coating defects.
